Especificaciones Técnicas
| Channels | 5 – 3 |
| POWER SUPPLY | |
| Power supply voltage | 9 ÷ 16 VDC |
| ldling current (power ON/OFF): | 1.8 A / 0.04 mA |
| Consumption@ 1Ω, 14.4 VDC (Max Musical Power): | 70 A |
| Remote In: | 7 ÷ 15 VDC – 1 mA |
| AMPLIFIER STAGE | |
| Distortion – THD (100Hz @ 4Ω): | <0,05% |
| Bandwidth: | 10 ÷ 42 kHz |
| S/N Ratlo (A welghted @ 1 V): | 102 dB |
| Damping factor (100Hz @ 4Ω) | 130 |
| Pre-ln sensitivity: | 0.2 ÷ 5 VRMS |
| Pre-ln impedance: | 10 kΩ |
| Load impedance (MIN) @5Ch: @3Ch: |
2Ω 4Ω + 4Ω + 2Ω |
| Weight (kg/lb): | 3.72 / 8.2 |
| Adjustable Crossovers | yes |
| OUTPUT POWER (RMS) @ 14.4 VDC, THD 1% | |
| 5Ch | 130 W x 4 (4Ω) + 490 x 1 (4Ω) |
| 5Ch | 220 W x 4 (2Ω) + 820 W x 1 (2Ω) |
| 3Ch | 440 W x 2 (4Ω) + 490 W x 1 (4Ω) |
| 3Ch | 440 W x 2 (4Ω) + 820 W x 1 (2Ω) |
| Total Power | 1700 W |
