Especificaciones Técnicas
5-Channel Full Range Class D Amplifier with 9-Channel
Digital Sound – 512k
Power Output:
CH1-CH4: 4 x 45 Watts RMS @ 4 Ω
CH5 (SUB): 1 x 180 Watts RMS @ 4 Ω
CH1-CH4: 4 x 50 Watts RMS @ 3 Ω
CH5 (SUB): 1 x 300 Watts RMS @ 2 Ω
Dimensions: 5.91″(W) × 1.77″(H) × 4.13″(L) (150 × 45 × 105 mm)
Inputs: High-Level 4 (6–18 V RMS with EPS®)
AUX RCA 2 (2–6 V RMS)
Optical Stereo PCM 1
• Frequency Response: 10 Hz–20 kHz (–3 dB)
• S/N Ratio: 95 dB (A-weighted)
• THD: 0.01% (1 kHz @4Ω, 10 W)
• Damping Factor: >80 (1 kHz, 2 V RMS, 4Ω)
Minimum Load Impedance: 3Ω (per channel), 2Ω (subwoofer)
