Especificaciones Técnicas
Distortion – THD, 1 kHz @ 4 Ω, 5 W: 0.01 %
Bandwidth -3 dB, 2 V/RMS, 4 Ω @ -1 dB: 10 Hz – 22 kHz
S/N ratio @ A weighted, 1 V, Max. Power: 100 dB
Damping factor @ 1 kHz, 2 V/RMS, 4 Ω: 75
Input Sensitivity:
3 – 24 V/RMS (high-level)
0.7 – 6 V RMS (low-level)
Input Impedance: 18 Ω (high-level)
Load Impedance (Min.):
4 CH @ 2 Ω
2 CH bridged @ 4 Ω
Output Power RMS @13.8 VDC, 1% THD:
4 x 55/95 Watts @ 4/2 Ω
2 x 200 Watts bridged @ 4 Ω
Output Power RMS @ 14.4 VDC, 1% THD:
4 x 60/100 Watts @ 4/2 Ω
2 x 220 Watts bridged @ 4 Ω
