Especificaciones Técnicas
| Channels | 4 – 3 – 2 |
| Amp class | AB |
| POWER SUPPLY | |
| Nominal power supply voltage (fuse) | 11 ÷ 15 VDC (2 x 25 A) |
| Operating power supply voltage | 6.5 ÷ 16.5 VDC |
| Idling current | 0.85 A |
| Standby current draw | 10 uA |
| Consumption, MIN load impedance (Max Musical Power) | 30 A |
| Remote IN | 4 ÷ 15 VDC (1.5 mA) |
| ART – Automatic Remote Turn on/off from SPK-IN (BTL radio only) | 1.5 VDC |
| Efficiency | 60% |
| AMPLIFIER STAGE | |
| Distortion – THD @ 100 Hz, 70% Rated Power | 0.01% |
| Damping factor @ 1 kHz, 1W | 130 |
| Bandwidth @ -3 dB | 10Hz ÷ 45kHz |
| S/N ratio (A-weighted @ 1 V Input) | 101 dBA |
| Minimum load impedance | |
| @ 4 Ch: | 2 Ω |
| @ 3 Ch: | 2 Ω + 2 Ω + 4 Ω |
| @ 2 Ch: | 4 Ω |
| Adjustable Crossovers | yes |
Potencia
| Output power (RMS) @ 1% THD: | |
| 4Ch @ 4Ω | 75 W x 4 |
| 4Ch @ 2Ω | 105 W x 4 |
| 3Ch @ 4Ω | 75 W x 2 + 210 W x 1 |
| 3Ch @ 2Ω / 4Ω | 105 W x 2 + 210 W x 1 |
| 2Ch @ 4Ω | 210 W x 2 |
| Output Power (RMS) @ 14.4 VDC, THD 10%: | |
| 4Ch @ 4Ω | 90 W x 4 |
| 4Ch @ 2Ω | 125 W x 4 |
| 3Ch @ 4Ω | 90 W x 2 + 250 W x 1 |
| 3Ch @ 2Ω / 4Ω | 125 W x 2 + 250 W x 1 |
| 2Ch @ 4Ω | 250 W x 2 |
| Total Power | 500 W |
