Especificaciones Técnicas
| Channels | 4 – 3 – 2 |
| Amp class | D |
| POWER SUPPLY | |
| Nominal power supply voltage (fuse) | 11 ÷ 15 VDC (1 x 40 A) |
| Operating power supply voltage | 9 ÷ 18 VDC |
| Idling current | 1.15 A |
| Standby current draw | 4.2 uA |
| Consumption, MIN load impedance (Max Musical Power) | 32 A |
| Remote IN | 4 ÷ 17 VDC (1 mA) |
| ART – Automatic Remote Turn on/off from SPK-IN (BTL radio only) | 1.5 VDC |
| Efficiency | 85% |
| AMPLIFIER STAGE | |
| Distortion – THD @ 100 Hz, 70% Rated Power | 0,02 % |
| Damping factor @ 1 kHz, 1W | 100 |
| Bandwidth @ -3 dB | 10 Hz ÷ 47k Hz |
| S/N ratio (A-weighted @ 1 V Input) | 101 dBA |
| Minimum load impedance | |
| @ 4 Ch: | 2 Ω |
| @ 3 Ch: | 2 Ω + 2 Ω + 4 Ω |
| @ 2 Ch: | 4 Ω |
| Adjustable Crossovers | yes |
| Output power (RMS) @ 1% THD: | |
| 4Ch @ 4Ω | 110 W x 4 |
| 4Ch @ 2Ω | 190 W x 4 |
| 3Ch @ 4Ω / 4Ω | 100 W x 2 + 400 W x 1 |
| 3Ch @ 2Ω / 4Ω | 190 W x 2 + 380 W x 1 |
| 2Ch @ 4Ω | 380 W x 2 (4Ω) |
| Total Power | 760 W |
